Centre for Solar Energy Materials (CSEM)

Overview

Due to reduced material and energy input thin-film provides still advantages compared to crystalline silicon-based PV technologies. In terms of cost per watt and efficiency of Cu(In,Ga)Se2 (CIGS) solar cell is considered to be the most promising thin-film PV technology. The efficiency evolution of CIGS during the last few years has been the most impressive within the thin-film materials, moreover comparable to multi-crystalline silicon cells and even more efficient than amorphous silicon (a-Si) and cadmium telluride (CdTe) while using a minimum of materials to produce. The current challenges include reducing the manufacturing cost and faster transfer of R&D results to industrial production. Due to the fact that the CIGS manufacturing process is more complex and less standardized than for other types of cells, it is necessary to select appropriate process route and maintain the manufacturing as flexible as possible. A monolithically integrated CIGS thin film solar cell on 300 mm x 300 mm being research and developed at ARCI has promising features over the existing technologies

Key Features

• Unique non-toxic two step, sputtering of precursor and atmospheric selenization process.
• Device configuration: Ag/AZO/ZnO/CdS/CIGS/Mo/Glass
• Tooled to make monolithically integrated CIGS thin film solar modules on 300 mm x 300 mm.
• Potential to make device on flexible substrates.

Potential Applications

• Building integrated photovoltaics (BIPV)
• Application for DC power appliance

Intellectual Property Development Indices (IPDI)

• Maximum photo conversion efficiency of 8.2% on lab scale device
• Developed 50 x 50 mm monolithically integrated module with 5% efficiency.
• Demonstrated running 2V DC motor with propeller with the power output from mini module.
• Improvement in device performance on lab scale and module level is underway

I-V of CIGS thin film solar cell on lab device

I-V of monolithically integrated 50 mm x 50 mm module (Inset: Picture of in-house developed module)

Major Patents / Publications

Major Publications

• Process parameter impact on properties of sputtered large-area Mo bilayers for CIGS thin film solar cell applications, Amol C. Badgujar, Sanjay R. Dhage*, Shrikant V. Joshi, Thin Solid Films 589 (2015) 79–84
• Transparent conducting Al:ZnO thin film on large area by efficient cylindrical rotating DC magnetron sputtering. Sanjay R. Dhage* and Amol C. Badgujar, Journal of Alloys and Compounds Vol 763, (2018) 504
• Process parameter impact on selective laser ablation of bilayer Molybdenum thin films for CIGS solar cell applications, Amol C. Badgujar, Shrikant V. Joshi and Sanjay R. Dhage*, Materials Focus 7 (2018) 1-7

Overview

CIGS-based solar cells are one of the most promising thin film solar cell technology with steadily improving cell efficiencies and large-scale commercial manufacturability. Although conventional CIGS technology was established on rigid glass substrates, significant progress has been made during the last decade in the direction of developing ‘flexible’ CIGS panels made on polymer film and metal foil substrates. This has opened a niche market for CIGS based products in the form of standalone charging solutions for transportation systems and portable electronics. At ARCI, flexible CIGS solar cells are being developed on stainless steel foils for use in portable charging applications.

Key Features

• Well established vacuum based sputtering and selenization route for making high quality CIGS absorbers on flexible substrates
• Easily scalable, dip coated Fe-diffusion barrier layer between SS substrate and Mo back contact
• Thin, flexible and lightweight CIGS mini-modules
• Possibility to integrate CIGS base charging solution into common daily use items like backpacks and umbrellas

Potential Applications

• Portable chargers for consumer electronics
• Mobility systems such as mini-drones and UAVs
• Standalone off-grid lighting solutions
• Building integrated PV

Intellectual Property Development Indices (IPDI)

• Established baseline processes to fabricate CIGS cells on SS foils
• Working lab-scale devices made and I-V performance evaluated

Overview

Flexible photovoltaics (PV) are the need of the hour for various energy applications. Cu(In,Ga)Se2 (CIGS) possessing large absorption coefficient and excellent log-term stability is a potential candidate for flexible PV with already demonstrated commercial maturity. However, cost is the major aspect for portable energy applications even with a slight compromise on device efficiencies. Electrodeposition having the ability for roll-to-roll manufacturing with lower capital investment is among the most explored processes for CIGS. Pulse electrodeposition is an advanced feature which significantly simplifies the conventional process while improving the absorber quality owing to its crucial pulse parameters is being pursued for the realization of low-cost flexible CIGS solar cells. Additionally, an all non-vacuum based CIGS solar cell on Mo substrates is being fabricated with other device layers like CdS, ZnO and AZO are solution processed while ZnS is also used as replacement for CdS towards Cd-free CIGS solar cells.

Key Features

• A simple economic pulse electrodeposition route for CIGS solar cells
• Efficient utility of electroreduction and oxidation phenomena
• Process devoid of any complexing agents, additives and third reference electrode
• Suitable for large area and roll-to-roll manufacturing on flexible substrates

Potential Applications

• Portable energy needs
• Building integrated photovoltaics
• Photoelectrochemical cells

Intellectual Property Development Indices (IPDI)

• Demonstration of 6.1 % efficient CIS solar cells at laboratory scale
• Scale up of uniform CIGS absorbers till 8 x 8 cm2

Major Patents / Publications

Major Publications

• B. V. Sarada, Sreekanth Mandati and Shrikant V. Joshi, A novel electrochemical method for manufacturing CIGS thin-films containing nanomesh-like structures, Patent filed, File No: 426/DL/2015, Date: 16th February, 2015
• Sreekanth Mandati, S. R. Dey, S. V. Joshi and B. V. Sarada, Cu(In,Ga)Se2 Films with Branched Nanorod Architectures Fabricated by Environmental-friendly Pulse-reverse Electrodeposition Route, ACS Sustainable Chemistry and Engineering 6(11), 13787 (2018)
• Sreekanth Mandati, Suhash R. Dey, Shrikant V. Joshi and Bulusu V. Sarada, Two-dimensional CuIn1-xGaxSe2 Nano-flakes by Pulse Electrodeposition for Photovoltaic Applications, Solar Energy 181, 396 (2019)
• Divya B, Sreekanth Mandati, Ramachandraiah A, Bulusu V. Sarada, Room Temperature Pulse Electrodeposition of CdS Thin Films for Application in Solar Cells and Photoelectrochemical cells, ECS Journal of Solid State Science and Technology 7(8), P440 (2018)

Overview

Non-vacuum processes have great interest for low cost chalcopyrite based photovoltaic technologies in CIGS thin film solar cell fabrication. A key feature in these processes is the selenization treatment has significant impact on the microstructure of the absorbers and, in turn, are determining for the performance of the device. In this context, a two step non-vacuum process, spraying of sonochemically synthesized CIGS nanoparticles suspension followed by post treatment (IPL/laser treatment or atmospheric selenization). A non-vacuum based route using Photonic sintering, novel atmospheric pressure thermal annealing is being developed to reduce the number of processing steps in complete cell fabrication and has great potential to be incorporated in to roll-to-roll manufacturing of cost effective CIGS thin film solar cells.

Key Features

• Scalable non vacuum manufacturing process for CIGS without toxic selenization
• Simple ambient sonochemical synthesis for CIGS NP’s with high material utilization
• Solution process using spraying technique
• Environmentally benign flash light and/laser post-treatment method
• Processing on Light weight and flexible glass substrate

Potential Applications

• Building integrated photovoltaic (BIPV)
• Application for DC Power Aplliance
• Powering Internet on things (IOT) based applications

Intellectual Property Development Indices (IPDI)

• Fabricated device demonstrated photo conversion efficiency exceeding 4% on lab scale
• Performance improvement by fine tuning the process parameters is underway

IV curve of non-vacuum processed CIGS thin film solar cell

Surface morphology of CIGS thin film absorber on Mo glass by non-vacuum ink based route

Major Patents / Publications

Major Publications

• Improved method of manufacturing copper-indium-gallium diselenide thin films by laser treatment. Patent application No: 2084/DEL/2212, Date: 05/07/2012, Inventors: Sanjay R. Dhage, Manish Tak and Shrikant V. Joshi
• Sonochemical synthesis of CuIn0. 7Ga0. 3Se2 nanoparticles for thin film photo absorber application, Amol C. Badgujar, Rajiv O. Dusane and Sanjay R. Dhage, Material Science in Semiconductor Processing 81 (2018) 17.
• Cu (In, Ga) Se 2 thin film absorber layer by flash light post-treatment, Amol C. Badgujar, Rajiv O. Dusane and Sanjay R. Dhage, Vacuum 153 (2018) 191.

Overview

The existing high temperature and vacuum processing and selenization treatment used in CIGS thin film solar cell fabrication are neither cost effective nor easily scalable to high volume production. Non-vacuum processes have great interest for low cost chalcopyrite based photovoltaic technologies. A key feature in these processes is the selenization treatment has significant impact on the microstructure of the absorbers and, in turn, are determining for the performance of the device. In this context, a two-step non-vacuum process (inkjet printing and selenization) for the preparation of CIGS absorber layer is being developed at ARCI. The process is novel and expected to have large impact in CIGS PV industry in terms of cost reduction and easy processing. Moreover, the non-vacuum route will reduce the number of processing steps in complete cell fabrication.

Key Features

• Scalable Inkjet printing process for quality CIGS thin film absorber preparation
• High material utilization technique because of drop on demand feature
• Mask-less and non-contact approach
• Fast and cost effective atmospheric pressure RTP selenization process
• Processable on Light weight and flexible glass substrat.

Potential Applications

• Building integrated photovoltaics (BIPV)
• Application for DC power appliance

Intellectual Property Development Indices (IPDI)

• Achieved 4.7% photo conversion efficiency on lab scale device
• Proved technical feasibility of process and proof of concept
• Performance improvement and evaluation underway

Schematic of inkjet printing of CIG precursor film

AM1.5 and Dark I-V of ink jet processed CIGS thin film solar cell (inset: Device x-section)

Major Patents / Publications

Major Publications

• Chalcopyrite CIGS absorber layer by inkjet printing for photovoltaic application, Brijesh Singh Yadav, Suhash Ranjan Dey and Sanjay R Dhage, material today proceedings, volume 4, issue 14 (2017)12480-12483
• Effective printing strategy for Cu (In, Ga) Se2 thin film absorber using aqueous ink for solar cell application” Brijesh Singh Yadav, Suhash Ranjan Dey and Sanjay R Dhage, Solar Energy 179 (2019) 363–370
• Role of selenium content in selenization of inkjet printed CIGSe2 thin film solar cell” Brijesh Singh Yadav, Suhash Ranjan Dey and Sanjay R Dhage, AIP Conference Proceedings 2082 (2019) 050001

Overview

Indian industrial sector needs both power and thermal energy for their manufacturing processes. Recently, Indian industries shown interest in exploit renewable energies, especially solar energy, due to their economic and environmental-friendly advantages. In this regard, centre for solar energy materials, ARCI has developed a cost-effective selective coating to convert solar radiation into a heat which can be used for low and medium temperature industrial process heat applications. We followed a facile wet chemical route using a combination of novel chemical oxidation, sol-gel and nanoparticle coating methods. The developed high selective receiver tube offers good mechanical strength along with high corrosion resistance. The high-performance cost-effective receiver tube with a capability of facile upscaling attracting many industries and technology has been transferred to an Indian industry as non exclusive basis (Greenera Energy India Pvt. Ltd).

Key Features

• High selective properties (Solar Absorptance ~95%; Spectral emittance ~0.12)
• Low heat loss property: ~0.14 at 250 °C
• Temperature stability: < 250 °C
• High corrosion resistance > 200 hrs withstand in salt spray test (ASTM B117)
• High mechanical stability

Potential Applications

• Solar hot water & Sea water desalination
• Solar drying and Cooking
• Space and Swimming pool heating
• Solar cooling
• Industrial process heat applications
• Power generation

Intellectual Property Development Indices (IPDI)

0.5-meter tandem absorber ,4-meter prototype receiver tube

Major Patents / Publications

Major Publications

• Filed an Indian patent application no 2142/DEL/2015 on 15/07/2015

Overview

Self-clean (easy to clean) technology is generally related to protect the solar devices from dust/dirt, corrosion and all sorts of weather conditions. PV panels are very important solar devices traditionally mounted outdoors on rooftops or in wide open spaces where they can maximize their exposure to sunlight. Unfortunately, this type of outdoor placement of the devises is subjected to substantially constant weather and moisture exposure. Due to this constant and extended exposure to the devices are preferably designed for using many years of stable and reliable operation without failure due to moisture damage. A general challenge is finding one protective coating (single layer) that has best-in-class qualities of selfclean property (easy to clean property), high weather and mechanical stabilities, no loss in transmittance/power conversion efficiency after deposition on PV panels and curable by ambient conditions. ARCI’s new technology will provide solution for the above-mentioned issues.

Key Features

• Low cost production (simple coating technique / easy scalable / curable by ambient temp.)
• Highly transparent coating (no loss in transmittance / power conversion efficiency after deposition)
• Super hydrophobic property: > 110 0 water contact angle
• High weather stability (withstand long duration accelerated test (IEC 61646)
• High mechanical stability
• Low dust deposition compared to bare and other commercial coated samples

Potential Applications

• PV panels & reflectors employed in CSP
• Optical lenses
• Video display panels
• Architectural glasses
• Textiles
• Plastic & concrete surfaces
• Ceramic tiles

Intellectual Property Development Indices (IPDI)

ARCI Nano coating on PV panel & glass (insert) compared with bare PV panel & glass

Optical trans. of PV cover glass & power conversion efficiency of PV module

Major Patents / Publications

Major Publications

• Indian patent Application no. 402/DEL/2014, date of filling: 13.02.2014.
• Indian patent Application no. 201911009429, date of filling: 11.03.2019.

Overview

Titanium dioxide (TiO2), the most promising photocatalytic material is already used in various practical applications, such as sterilization, deodorization, self-cleaning and super hydrophilic functionality by the strong oxidizing agents (holes and free radicals) thereof being generated after exposure to light. Conventional TiO2 materials most preferably prepared from sol-gel, and other conventional methods can active (generating oxidizing species) only under the exposure to UV lights because of its large band gap of 3.20 eV. Moreover, if a conventional TiO2 material is illuminated with visible light (>400nm), oxidizing species cannot be formed because of no charge carrier formation. To activate in the visible light, incorporation of a few weight percent of smart carbon in the form of nanoparticles or sensitized carbon either in the bulk or at the surface of titanium dioxide leads to visible-light and sunlight active suitable for indoor and outdoor self-cleaning applications. The technology of smart carbon based TiO2 nanostructure materials are available in the form of paste, suspension and thin films having highest visible and sunlight photocatalytic self-cleaning properties and they can be easily applied to any type of device/ object.

Key Features

• Highly visible and sunlight photocatalytic properties
• Good dispersion in solvents
• High stability under solar and UV light
• Easily incorporate into any type of device/object (e.g. fabrics or paints or ceramic tiles etc.)

Potential Applications

• Self-clean fabrics/ceramic tiles manufacturing
• Indoor and outdoor self-cleaning paint manufacturing
• Self-clean coatings for antibacterial and antifouling applications

Intellectual Property Development Indices (IPDI)

• Prototype fabric has been developed and validated.
• Technology transfer are being progressed

Outcome

• A technology of smart carbon based TiO2 nanostructure materials has been successfully developed and demonstrated for indoor and outdoor self-cleaning applications

TEM and HR-TEM images, Photocatalytic decomposition of acetaldehyde

Mechanism of self-cleaning process

Major Patents / Publications

Major Publications

• Filed an Indian patent. Application No: 201811011478

Overview

Spectrally selective receiver tube is the critical component in Concentrated Solar thermal (CST) technology. To increase the overall efficiency of a CST system, we need high thermal stable spectral selective coating which can be operated at ≤500 °C and should sustain minimum of 25 years without any functional degradation. In order to meet the challenge, we designed and developed a high performance solar selective coating with spinel structures by using transition metals like Mn, Cu and Ni by wet chemical method. Spinel’s are amenable to the substitution of a large number of transition metals to tune the optical properties with high thermal stability. We employed a facile low cost wet chemical method to develop coatings.

Key Features

• High solar absorptance αsol= 0.97 & Low emittance ε = 0.16
• Spinel based nanocomposite oxide
• Thermally sable coating up to 500 °C
• Cost effective

Potential Applications

• Stream generation for various industrial applications
• Power generation
• Solar water heater /Solar dryer
• Solar desalination

Intellectual Property Development Indices (IPDI)

Major Patents / Publications

Major Publications

• Indian patent application no. 2142/DEL/2015, date of filling: 15.07.2015.
• Solar Energy Materials and Solar Cells 174 (2018) 423–432

Overview

Dual Functional (Anti-Reflective & Anti-Fogging) coatings are important for transparent materials. Anti-fogging and Antireflective coatings are now often used on transparent glass or plastic surfaces used in optical applications, such as the lenses and mirrors found in glasses, goggles, camera lenses, and binoculars. These functional coatings attracted a great attention. Dual functional coating (Antireflective with Anti-fogging properties) with high optical transmittance (> 96% on glass; >94% on optical lens), and high weather stability (> 100 h Environmental chamber test) has been successfully developed. It exhibits high super hydrophilic property < 5o or any other type of devices that require minimal reflection.

Key Features

• High transmittance (>95 %)
• Low temperature curable (<100 °C)
• Weather stable (withstands humidity > 90 %)
• Highly mechanical stable and Long durability
• Highly Super-hydrophilic (Contact Angle < 5°)

Potential Applications

• Solar PV & CSP cover glass
• Optical lenses
• Video display panels
• Architectural glasses
• Automobile window shields

Intellectual Property Development Indices (IPDI)

Optical transmittance of coatings on glass tube & optical lens

Prototype Receiver Design and 1 m AR coated CSP cover glass tube

Major Patents / Publications

Major Publications

• Indian patent application no. 2919/DEL/2013, date of filling: 3.10.2013.

Overview

In recent years, there has been increasing interest in the application of nanoparticles in various fields because of its large effective area which enhances the surface reactions. Titanium dioxide (TiO2) & Zirconium dioxide (ZrO2) are the most important industrial materials that have been used for white pigments for a long time owing to its high refraction characteristic. Further, it is one of the main components of piezoelectric materials, dielectrics, and semi-conductors according to the development of electronic industry since it is characterized by a high dielectric constant. Still further, it has been the trend recently that its application to cosmetics, fillers, paints, lubricants, precision ceramics, anodic materials (DSSC and Perovskite, battery, etc.) functional coatings (Antireflective, corrosion protection, barrier layers, etc.) and using UV shielding and absorbance properties as well as a catalyst for removing organic contaminants according to the chemical corrosion resistance and photocatalytic effect has been extended rapidly. To view of the vast applications, the primary objective of this project work is to focus to develop highly crystalline TiO2 and ZrO2 nanoparticles along with high dispersion and uniformity suitable for the above mentioned applications.

Key Features

• High crystalline
• Uniform particle size
• Good dispersion in polar solvents
• High photocatalytic property
• Easily incorporate into any type of device/ object

Potential Applications

• Photoanodes for DSSC and Perovskite solar cells
• Self-clean fabrics/ceramic tiles and glass manufacturing
• Coatings for corrosion resistance and barrier applications

Intellectual Property Development Indices (IPDI)

• Crystalline TiO2 and ZrO2 nanoparticles have been successfully developed by lyothermal synthesis & investigated photovoltaic and photo catalytic properties of the materials.

Outcome/Expected outcome:

• Highly dispersible crystalline nanoparticles were successfully developed & validated for solar cell and photocatalytic self-cleaning

TEM morphology of ZrO2 & TiO2 nanoparticles

Photovoltaic and Photocatalytic performance of TiO2 and ZrO2 nanoparticles

Overview

Solar collectors are very important devices for increasing energy efficiency in concentrated solar thermal power (CSP) for various industrial applications. Low to medium temperature stable solar absorber coating plays an important role in industrial process heat, desalination and solar hot water applications . For such application, coatings on large area and generation of solar receiver tubes are required by an economic way is one main objective to reduce the cost of power generation from solar energy. The technology involves an economical, efficient and environmental friendly non-chrome based absorber coatings by electrodeposition route

Key Features

• Cost effective and environmental friendly non-chrome based electrodeposition route
• High optical properties (solar absorptance: 94-95 % and thermal emittance: <0.20 (at 300°C)
• Temperature of operation: <300°C
• Good mechanical and weather stability

Potential Applications

• Stream generation for various industrial applications
• Solar water heater
• Solar desalination
• Solar dryer

Intellectual Property Development Indices (IPDI)

• Performance and stability are validated at laboratory scale
• Scale up of electrodeposited coating development are completed

Highlights

• Csp of 1977 F/g at 1 A/g by half cell and 91.5 F/g at 0.5 A/g by full cell analysis
• Maximum energy density of 28.59 Wh/kg and a power density of 7.5 kW/kg
• 74% capacitive retention for 5000 cycles

Image of non-chrome based absorber coating on SS tube and copper foil

Major Patents / Publications

Major Publications

• Indian patent to be filed

Overview

With the anticipated increase in the renewable wind and solar energy supercapacitors with high specific capacitance and cycle stability have increasing demands to balance the energy storage requirements. NiCo2O4 based electrode materials with excellent electrochemical performance and high theoretical specific capacitance values serve as emerging tool for various applications like HEV’s and back-up systems. Further, electrodeposition is a cost-effective mode of synthesis both with respect to the materials employed and the equipment used. The technology aims at the synthesis of binder free electrodeposited NiCo2O4 electrode materials for supercapacitors along with the fabrication of device for practical applications

Key Features

• Cost effective synthesis strategy
• High specific capacitance (1977 F/g at 1 A/g by half cell and 91.5 F/g at 0.5 A/g by full cell)
• High power density (7.5 kW/kg at 10 A/g)
• Good capacitive retention of the ASC (74% retention for 5000 cycles)

Potential Applications

• Start-Stop systems
• HEV’s
• UPS and back-up systems
• Electronics

Intellectual Property Development Indices (IPDI)

• ASC device performance and stability for 5000 cycles has been validated at lab scale

Morphology and Electrochemical Characterizations

Major Patents / Publications

Major Publications

• Manuscript yet to be published

Overview

The enhancement of thermal behavior of Heat transfer fluid (HTF) by using high specific heat capacity nanostructure materials such as smart carbon ( Carbon Nano Clusters (CNCs), Layer Structured Carbon and Graphene nanocomposite) based materials can be provided enormous benefits for heat transport phenomena which are primary importance to solar thermal power generation and industrial heat transportation. Due to nanometer-scale materials, particles are well stable without sedimentation.

Key Features

• High heat capacity & thermal conductivity
• High specific surface area and therefore more heat transfer surface between particles and liquids
• Reduced sedimentation & pumping power
• Adjustable thermal properties
• Cost effective and easy to prepare
• 27% enhancement in specific heat capacitance

Potential Applications

• Industrial cooling applications
• Solar thermal power plants
• Extraction of geothermal power and other energy sources
• Cooling of Microchips
• Lubricants

Intellectual Property Development Indices (IPDI)

Commercial HTF & ARCI’s nano HTF

Carbon Nanoclusters (CNCs) Graphene nanocomposite, Specific Heat capacity of Graphene nanocomposite based HTF

Overview

Al:ZnO (AZO) has emerged as popular transparent conducting electrode material replacing conventional indium tin oxides (Sn:In2O3) and fluorine doped tin oxide (F:SnO2) as non-toxic, cheaper and available in abundance. AZO thin films finds application in wide range of areas such as solar cells, flat panel displays, organic light emitting diodes, gas sensors, photo-catalysis, transistors, and electromagnetic interference shields (EMIS) and piezoelectric devices. Apart from exclusive use in CIGS thin film solar cells, AZO is widely being applied as transparent conducting contact in dye sensitized, perovskite, CdTe and Si based solar cells. DC magnetron systems with cylindrical rotating targets was used for large area deposition, which has advantages of possess high plasma density, faster deposition rate and enables better control over the sputter deposition process, required for high thickness uniformity over large area. Best resistivity and transmittance with high thickness uniformity on 300 mm x 300 mm glass substrate was achieved on the AZO thin films sputtered using optimized process conditions considering technological aspect.

Key Features

• AZO thin films with high transmittance and conductivity on 300 mm x 300 mm glass substrate
• Highly uniform films (Std deviation 20.65%) with visible light optical transmittance 84% and least resistivity of 4.07 X 10-4 ohms.cm.
• Figure of merit confirms the suitability of AZO thin films for various optoelectronic device applications as compare to other existing TCO films.

Potential Applications

• Solar energy
• Electrical and electronics
• Sensors

Intellectual Property Development Indices (IPDI)

• Application development completed

Transmission curve of AZO thin film on glass (Inset: SEM X-Section image)

Major Patents / Publications

Major Publications

• Transparent conducting Al:ZnO thin film on large area by efficient cylindrical rotating DC magnetron sputtering. Sanjay R. Dhage* and Amol C. Badgujar, Journal of Alloys and Compounds Vol 763, (2018) 504

Overview

CIGS solar cell fabrication begins with sputter coated Molybdenum (Mo) on soda lime glass (SLG) substrate which acts as a back contact, likewise Mo thin film back contact is also exclusively being used in CZTS, CdTe and Sb2Se3 thin film solar cells. Moreover, Mo thin films has wide range of applications, as an electrode in optoelectronical systems. Properties of Mo thin film are dependent upon various sputtering parameters such as power, pressure and substrate temperature. Precise optimization of sputter process parameters such as sputtering power and deposition pressure in the bilayer approach can effectively achieve high electrical conductivity and strong adhesion; in addition, substrate cleaning and surface treatment play a crucial role influencing adhesion between SLG and Mo thin film. Surface conditioning of glass substrate to sputter coat adherent thin films via cost-effective, scalable, environmentally benign process has potential technological benefits. Sputtering process parameters were optimized on DC cylindrical rotating magnetron system to obtain stress free, conductive, well adherent and uniform Mo thin films on substrates of size 300 mm x 300 mm for contact applications.

Key Features

• Mo thin films of 500 nm thickness using rotating DC magnetron on SLG substrate of the size of 300 mm x 300 mm
• High uniformity of thickness (Std. Dev. 3.17%), best electrical (resistivity of 1.59E-05 ohm.cm), mechanical and optical properties of Mo thin film over large area.
• High reflectance in IR region
• High adhesion strength on Mo to glass substrate

Potential Applications

• Solar energy
• Electrical and electronics
• Sensor

Intellectual Property Development Indices (IPDI)

• Application development completed

FESEM X-Section image of Mo thin film on glass

Summary of best achieved properties of Mo thin film on glass

Major Patents / Publications

Major Publications

• Molybdenum bilayer thin film on large area by cylindrical rotating DC magnetron sputtering for CIGS solar cell application, Amol C. Badgujar, Brijesh singh Yadav, Suhash R Dey, Rajiv O. Dusane and Sanjay R. Dhage* Proceedings of 35th EUPVSEC 2018
• Effect of various surface treatments on adhesion strength of magnetron sputtered bi-layer molybdenum thin films on soda lime glass substrate, B.S.Yadav, Amol C. Badgujar and Sanjay R. Dhage*, Solar Energy 157 (2017) 507-513
• Process parameter impact on properties of sputtered large-area Mo bilayers for CIGS thin film solar cell applications, Amol C. Badgujar, Sanjay R. Dhage*, and Shrikant V. Joshi, Thin Solid films 589 (2015) 79-84

Overview

Themost promising technology for conversion of solar energy into electricity (renewable energy generation) and most widely commercialized technology include silicon (Si) solar technology, where recent advancements offers low manufacturing costs. Though Si photovoltaic technology has its high ground processing cost and difficult in manufacturing is still a bottleneck. To overwhelm the difficulty lot more alternative materials were fabricated and tested for better conversion efficiency. Among all 3rd generation organic-inorganic metal halide perovskite solar cells(PSCs) shown promising results with high power conversion efficiency (PCE), ease of fabrication cost with effortless fabrication techniques.Initial experiments started with a lab scale (15mm × 15mm PSC device dimension) conventional PSC device fabrication with the PCE of 16.2% as shown in Fig.1(a & b).

Key Features

• Tunable band gap and visible light transmittance
• Ease of fabrication process
• Non- vaccum based fabrication process

Potential Applications

• Automobile (auxiliary power generation)
• Off-grid power generation

Intellectual Property Development Indices (IPDI)

Photovoltaic performance of PSC device.

Major Patents / Publications

Major Publications

• Glass-to-glass encapsulation with ultraviolet light curable epoxy edge sealing for stable perovskite solar cells, Materials Letters, 250 (2019) 51–54.
• Hole-conductor free ambient processed mixed halide perovskite solar cells, Materials Letters, 245 (2019) 226-229.

Overview

The instability of perovskite solar cells against moisture, light and heatremains the main stumbling block towards the commercialization of this technology. One of the promising strategies is to lower the dimensionality of perovskites from three-dimensional (3D) to two-dimensional (2D) which presents higher stability against the ambient environment. The conductor layers are isolated from one another by incorporating R–NH3, a large aliphatic or aromatic alkyl ammonium spacer cation. The insertion of insulating spacer cations gives 2D layered perovskites unique properties compared to their 3D counterparts. The hydrophobic nature of the organic spacer imparts 2D perovskites with superior moisture stability, these quasi2D perovskites are used as absorber layers to impart highly efficient and stable perovskite solar cells.

Key Features

• High stability towards moisture
• Tunable bandgap

Potential Applications

• Off-grid power supply
• Building integrated photovoltaics (Smart windows, roof, tiles)
• Solar road studs

Intellectual Property Development Indices (IPDI)

Figure: a) ambient atmosphere stability studies, b)Contact angle measurement, c) Photovoltaic performance, d) photovoltaic stability

Major Patents / Publications

Major Publications

• Patent search under process

Overview

About 50% of the production costs of perovskite solar cells (PSCs) are accorded by the organic hole transporting materials (HTM) and the metal back contact. Using a highly conductive carbon electrode to replace both organic HTM and the metal back contact cuts down the production cost by 50%. Carbon-based materials, when used as back contacts in HTM-free PSCs, have been proved to be a class of cheap, stable, water-proof, and anticorrosive materials. By using screen printing technique large area with high uniformity and reproducible carbon based PSC can be made. As ongoing work, 100mm X 100mmcarbon based perovskite modules were developed.

Key Features

• Low material and production cost
• Highly stable perovskite devices

Potential Applications

• Off-grid power supply
• Building integrated photovoltaics (roof, tiles)
• Solar road studs

Intellectual Property Development Indices (IPDI)

Figure: Large area carbon based perovskite solar cell

Major Patents / Publications

Major Publications

• Room temperature curable carbon cathode for hole-conductor free perovskite solar cells, Solar Energy, Accepted

Overview

The constantly growing demand for optoelectronic and optical equipment in diverse areas, including consumer electronics and space exploration has created the need to identify the best ways to improve the efficiency of light collection. In this regard, development of broad-band anti-reflective coatings (BARCs) has attracted substantial research interest due to their high transmittance in a broad wavelength range (300–2500 nm). Due to their high refractive indices, optical elements like glass and polymeric transparent substrates suffer a reflection loss of about 8-9% in the visible spectrum of the solar radiation. Such reflection losses are undesirable and detrimental to the overall light to electricity conversion efficiency. Hence, BARCs that transfer maximum incident light over a broad range of wavelengths can help to achieve competitive conversion efficiencies in solar cells

Key Features

• High transmittances in visible and solar regions: >98 % (in visible)  >96% (in solar)
• Low temperature curable (80-1000C)
• High temperature stability: Max up to 10000C
• Weather stability: > 200hrs withstand in high humidity (>90%) at 500C
• High mechanical stability and Long durability
• Coat effective coating technique

Potential Applications

• Solar PV & CSP cover glass
• Optical lenses
• Video display panels
• Architectural glasses
• High power lasers

Intellectual Property Development Indices (IPDI)

Optical transmittance of BARC coated CR 39 lens compared with bare and commercial antireflective coated lens

Prototype Receiver Design and 1 m AR coated CSP cover glass tube

Major Patents / Publications

Major Patents*
